Large CNC Skiving Fin Machine For High Fin Density Heat Sink
- This large skiving machine is developed by our factory. The heat sink fin skiving machine is designed and selected according to the needs of large section scraper.
- High speed servo motor drive, improve the speed of the blade, save product processing time.
- Lori large CNC skived equipment adopts high quality main structural castings, which has the characteristics of design optimization and structural lightweight.
- The base is widened and lengthened with full support design and structural insight to ensure the heavy load capacity during processing.
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Advantages of CNC Skiving finMachine
- Reasonable structural strength and the combination of reinforcement bars provide high rigidity of the machine.
- This skived machine for heat sink fin is used for shovel teeth. The scraper has high precision, wide application range and easy operation.
- Parametric variable program, users only need to enter the tool parameters and related process parameters to achieve processing, no programming.
- High efficiency, unique numerical control technology, to ensure that the machine high-speed operation, stable and no impact.
- CNC skiving fin heat sink machine and skiving grinding tool holder, so that the skiving process change is simple and convenient, the cross tool holder has a quick return handle and an adjustable limit rod, can be quickly and accurately adjusted to the next cutting depth.
- The skiving machine is intelligent, data input, human-computer interaction interface, through simple data input can achieve automatic control processing.
Related Parameters
| Model No. | LRL-3010 | Vacuum pump power | 5.5 KW |
| X axis travel | 1000 (mm) | Gas tank (included) | 1m³ |
| Z axis travel（work surface） | 500 (mm) | Machine total power | 17KW (Not include vacuum pump) |
| Working desk size | 500*1100 (mm) | Control System | Taiwan lN |
| X axis moving speed | 10 meter/min | 150mm skiving cutter | One cutter |
| Z axis moving speed | 8 meter/min | Knife sharpener | One |
| Skiving fin maximum length | Copper 1000mm, Aluminum 1000m | X/Z axis screw | Taiwan HIWIN |
| Skiving fin maximum width | Copper 150mm, Aluminum 300mm | X/Z axis rai | Taiwan HIWIN |
| Skiving fin maximum thickness | Copper 1mm, Aluminum 2mm ( When the thickness of the fin is 2 mm, the maximum width of the heat sink does not exceed 200 mm ) | X/Z axis servo motor | Japan Yaskawa |
| Skiving fin minimum thickness | 0.06mm | Precision | Repeat positioning accuracy is less than 0.02mm |
| Skiving fin maximum step | 10mm | Bearing | Japan NSK |
| Skiving fin maximum height | Copper 60, Aluminum 120 mm | Dimensions | L3450 * W1510 * H2250 |
| Skiving fin minimum step | 1 to 2（Sheet Thickness vs. Step) | Overall weight (approx) | 6 tons |
sample pictures
This special CNC skiving machine skives the fins out of a single piece of material (copper or aluminum) to form a one-piece heat sink with the fins and base attached.
